Brother MFC-7390

To Next Page

To Previous Page

3-10

Confidential

2 ADF unit

Harness colors are subject to change for some reason.

ADF unit

FFC holder ASSY

Document scanner unit

ADF sensor harness

(WH, BL, BK)

ADF motor harness

(RD)

ADF ground harness

(OR)

Main PCB ASSY

ADF sensor harness unit

Second side CIS flat cable

ADF FFC holder
