3-47

Confidential

9.11.5 ADF separation holder ASSY

(1) Remove the Taptite cup B M3x10 screw to remove the ADF separation holder ASSY from

the ADF unit.

Fig. 3-38

ADF separation holder ASSY

ADF unit

Taptite cup B M3x10
