3-9

Confidential

7. HARNESS ROUTING

1 Handset holder ASSY, Speaker harness ASSY

Harness colors are subject to change for some reason.

Lower handset holder

Hook harness (WH)

Speaker harness ASSY

(RD)

Side cover L
