Brother MFC-7390

To Next Page

To Previous Page

3-14

Confidential

6 First side CIS unit, Panel

Harness colors are subject to change for some reason.

Flat core

First side CIS flat cable

Panel flat cable

FB ground harness (BK)

Document scanner motor harness (WH)

Document scanner

bottom cover ASSY

Panel ground harness

(BK)
