Brother MFC-7390

To Next Page

To Previous Page

3-62

Confidential

Fig. 3-54

Assembling Note:

• Fold the Panel flat cable at the positions described below.

45°

127±1

45°

223±1

401±2

413±2

Mountain fold

Valley fold

Reinforcing plate
