Brother MFC-7390

2-16
Confidential
Fig. 2-11
Side cover R
Back cover
Low-voltage power
supply PCB ASSY
Registration front/rear
actuator holder ASSY
Paper feed sensor PCB ASSY
Front cover ASSY
Paper tray
Side cover L
T1 clutch
Registration clutch
Fan
Laser unit
Inner chute ASSY
Outer chute ASSY
Fuser unit
Main shield plate
Main PCB ASSY
Motor drive sub ASSY
Duplex tray
Side cover L
(For models with handset)
Paper feed motor
Fuser gear
64R/36R
Eject sensor
PCB ASSY
New toner sensor PCB ASSY
High-voltage power
supply PCB ASSY
Fuser cover
Toner
cartridge
Drum unit
