Chapter 1
8
LCD screen 1
The LCD shows the current machine status
when the machine is idle.
1 Wireless Status
A four level indicator shows the current
wireless signal strength if you are using a
wireless connection.
2 Memory Status
Lets you see the available memory in the
machine.
3 Current Receive Mode
Lets you see the current receive mode.
Fax (Fax only)
F/T (Fax/Tel)
Mnl (Manual)
MC (Msg Ctr)
4 Voice messages in the machine’s memory
Shows how many received voice messages
are in the memory.
5New Fax
When Fax Preview is set to On, you can see
how many new faxes you have received.
6 Faxes in memory
Shows how many received faxes are in the
memory.
7 Fax Preview
Lets you preview received faxes.
8MENU
Lets you access the main menu.
9 Ink indicator
Lets you see the available ink volume.
Also, lets you access the Ink menu.
10 Speed Dial
Lets you search the number you want to
fax/dial.
11 Warning icon
Appears when there is an error or maintenance
message; press the Warning icon to view it,
and then press Stop/Exit to return to the
Ready screen.
12 Message Center
Lets you listen to and manage voice messages
and recorded conversations.
13 Call History
Lets you view a list of outgoing calls and the
caller ID history.
Also, lets you fax or call the number you have
chosen from the lists.
0Max
06:54
01.01.2010
01
03
03
New FaxNew Fax
01
New MSGNew MSG
Fax
Preview
Message
Center
Call History
Speed Dial
MENU
MC
Mem.
INK
5 68 9
11
12 10
74321
13
