Brother MFC-9840CDW Quick Setup Guide

Setting Up the Machine
8
STEP 1
6 Enter the two digits for the day on the dial pad,
and then press OK.
02.Date&Time
03/XX/2008
Day:25
Enter & OK Key
(e.g. Enter 2, 5.)
7 Enter the time in 24-hour format on the dial
pad, and then press OK.
02.Date&Time
03/25/2008
Time:15:25
Enter & OK Key
(e.g. Enter 1, 5, 2, 5 for 3:25 P.M.)
8 Press Stop/Exit.
Note
If you make a mistake, press Stop/Exit to start
from step 1.
7 Setting your station ID
You should store your name and fax number to be
printed on all fax pages that you send.
1 Press Menu.
2 Press 0.
3 Press 3.
4 Enter your fax number (up to 20 digits) on the
dial pad, and then press OK.
03.Station ID
Fax:_
Enter & OK Key
5 Enter your telephone number (up to 20 digits)
on the dial pad, and then press OK.(If your
telephone number and fax number are the
same, enter the same number again.)
03.Station ID
Fax:908XXXXXXXX
Tel:_
Enter & OK Key
6 Use the dial pad to enter your name (up to 20
characters), and then press OK.
03.Station ID
Fax:908XXXXXXXX
Tel:908XXXXXXXX
Name:
Enter & OK Key
Note
• Refer to the following chart for entering your name.
• If you need to enter a character that is on the same
key as the previous character, press to move
the cursor to the right.
• If you entered a letter incorrectly and want to
change it, press to move the cursor to the
incorrect character, press Clear/Back.
For more details, see Entering text
on page 48.
7 Press Stop/Exit.
Note
(USA only)The Telephone Consumer Protection
Act of 1991 makes it unlawful for any person to
use a computer or electronic device to send any
message via a telephone fax machine unless such
messages clearly contain, in a margin at the top or
bottom of each transmitted page, or on the first
page of the transmission, the date and time it is
sent and an identification of the business or other
entity or other individual sending the message and
the telephone number of the sending machines or
such business, other entity or individual.To
program this information into your machine, see
Setting the date and time on page 7 and Setting
your station ID on page 8.
Press
key
One
time
Two
times
Three
times
Four
times
Five
times
2 ABC2A
3 DEF 3D
4 GH I 4G
5 JKL5J
6 MNO 6M
7 PQRS7
8 TUV8T
9 WX Y Z 9

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
