Chapter 1
6
Control panel overview 1
MFC-J2310, MFC-J4410DW and MFC-J4610DW have the same 1.8" Touchscreen
LCD and Touchpanel.
1
Most of the illustrations in this User’s Guide show the MFC-J4410DW.
1 1.8" Touchscreen LCD (Liquid Crystal
Display)
This is a Touchscreen LCD. You can access
the menus and options by pressing them as
they are displayed on this screen.
You can adjust the angle of the Touchscreen
LCD and Touchpanel by lifting it. To lower this
control panel, push the release button that is
located behind the mark, as shown in the
illustration.
