Brother MFC-J4340DW User Manual

Home > Network > Network Features > Synchronize Time with the SNTP Server Using Web Based
Management > Configure the SNTP Protocol Using Web Based Management
Configure the SNTP Protocol Using Web Based Management
Configure the SNTP protocol to synchronize the time the machine uses for authentication with the time kept by
the SNTP time server.
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Network > Network > Protocol.
Start from , if the navigation menu is not shown on the left side of the screen.
5. Select the SNTP checkbox to activate the settings.
6. Click Submit.
7. Restart your Brother machine to activate the configuration.
8. Next to the SNTP checkbox, click Advanced Settings.
9. Configure the settings.
Option
Description
Status Displays whether the SNTP protocol is enabled or disabled.
Synchronization Status Confirm the latest synchronization status.
SNTP Server Method Select AUTO or STATIC.
• AUTO
If you have a DHCP server in your network, the SNTP server will
obtain the address from that server automatically.
• STATIC
Type the address you want to use.
Primary SNTP Server Address
Secondary SNTP Server Address
Type the server address (up to 64 characters).
The secondary SNTP server address is used as a backup to the
primary SNTP server address. If the primary server is unavailable,
the machine will contact the secondary SNTP server.
Primary SNTP Server Port
Secondary SNTP Server Port
Type the port number (1-65535).
The secondary SNTP server port is used as a backup to the primary
SNTP server port. If the primary port is unavailable, the machine will
contact the secondary SNTP port.
Synchronization Interval Type the number of hours between server synchronization attempts
(1-168 hours).
10. Click Submit.
Related Information
• Synchronize Time with the SNTP Server Using Web Based Management
Related Topics:
• Access Web Based Management
320

Brother MFC-J4340DW Specifications

General

N-up printing	2, 4, 9, 16
Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	20 ipm
Print speed (ISO/IEC 24734) color	19 ipm
Time to first page (black, normal)	5.8 s
Time to first page (color, normal)	5.9 s
Duplex print speed (ISO/IEC 24734) mono	10 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, draft quality, A4/US Letter)	35 ppm
Print speed (color, draft quality, A4/US Letter)	29 ppm
Print speed (black, normal quality, A4/US Letter)	- ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 2400 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10.5 s
Time to first copy (color, normal)	13 s
Scan to	E-mail, FTP, File, Image, Network folder, OCR, PC, USB
Scan drivers	TWAIN
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	213.9 x 295 mm
Output color depth	24 bit
Duplex scanning mode	Manual
Maximum scan resolution	19200 x 19200 DPI
Faxing	Color faxing
Fax memory	180 pages
Fax transmission speed	14400 sec/page
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	30000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	4
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	20 sheets
Envelopes sizes	C5, Com-10, DL, Monarch
Photo paper sizes	9x13, 10x15, 13x18 cm
Duplex media weight	64 - 105 g/m²
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO C-series sizes (C0...C9)	C5
Multi-Purpose Tray media weight	64 - 300 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, EAP-FAST, EAP-TLS, EAP-TTLS, PEAP, SSID, SSL/TLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(AutoIP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, CustomRawPort/ Port9100, IPP, SNMPv1/v2c, TFTPserver, ICMP, Web Services(Print/Scan), SNTP Client, HTTPServer
Supported network protocols (IPv6)	NDP, RA, mDNS, LLMNRResponder, DNS Resolver, LPR/LPD, Custom Raw Port/ Port9100, IPP, SNMPv1/v2c, TFTPserver, WebServices (Print/Scan), SNTP Client, ICMPv6, HTTPServer
Cables included	AC
Maximum scan area (ADF)	213.9 x 353.6 mm
USB 2.0 ports quantity	2
Internal memory	128 MB
Sound pressure level (printing)	57 dB
Display	LCD
Control type	Buttons
Product color	White
Display diagonal	1.8 \
Market positioning	Home & office
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (sleep)	1.2 W
Power consumption (average operating)	21 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	Blue Angel
Package depth	242 mm
Package width	495 mm
Package height	455 mm
Package weight	10700 g
Pallet GTIN (EAN/UPC)	4977766808439
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	343 mm
Width	435 mm
Height	180 mm
Weight	8800 g
