4.2.2 No paper feeding from MP tray
<User Check>
• Check that the paper is set in the MP tray deeply.
• Check that too much paper is not loaded in the MP tray.
• Check if the machine is used with the MP tray support and MP flap are in closed state.
• Check that the thickness of the paper is 60 to 230 g/m
2
.
• Check that the paper tray is not set as the paper tray by the printer driver.
• Flip through the paper and reset it in the MP tray.
• Clean the MP paper pick-up roller.
• Check whether the paper tray is closed correctly.
Step Cause Remedy
1
MP roller holder ASSY
attachment failure
Reattach the MP roller holder ASSY
correctly.
2
Connection failure of the paper
feed motor flat cable
Reconnect the paper feed motor flat
cable.
3
Connection failure of the MP
paper empty/registration front
sensor harness
Reconnect the MP paper empty/
registration front sensor harness.
4
Paper feed motor flat cable
failure
Replace the paper feed motor flat cable.
5 Paper feed motor failure Replace the paper feed motor.
6
Damaged gears in the paper
feed drive system
Replace the frame L unit.
7 Damaged fuser unit Replace the fuser unit.
8 Main PCB failure Replace the main PCB ASSY.

Brother MFC-L2713DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 2400 x 600 dpi
Automatic Duplex Printing	Yes
Paper Input Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 15, 000 pages
Memory	64 MB
Processor	600 MHz
Scan Resolution	Up to 1200 x 1200 dpi
Fax Speed	33.6 kbps
Dimensions	410 x 398.5 x 318.5 mm
Weight	11.8 kg
Print Speed	30 ppm
Display	2-line LCD
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
