Brother MFC-L2713DW User Manual

3-26
Confidential
9.3 Back cover
(1) Open the Back cover.
(2) Push both Ribs on the Back cover outward, and remove the Pin on the Outer chute ASSY.
(3) Pull out the right side of the Back cover in the direction of the arrow A to remove it from the
Boss, and remove the Back cover in the direction of the arrow B.
Fig. 3-11
Boss
Back cover
Back cover
Pin
Rib
A
Outer chute ASSY
Rib
B
Boss

Brother MFC-L2713DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 2400 x 600 dpi
Automatic Duplex Printing	Yes
Paper Input Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 15, 000 pages
Memory	64 MB
Processor	600 MHz
Scan Resolution	Up to 1200 x 1200 dpi
Fax Speed	33.6 kbps
Dimensions	410 x 398.5 x 318.5 mm
Weight	11.8 kg
Print Speed	30 ppm
Display	2-line LCD
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
