9.17 Joint cover ASSY
(1) Remove the four Taptite bind B M4x12 screws.
(2) Release the Hooks in order of the Hook A to D, and remove the Joint cover ASSY in the
direction of the arrow.
Fig. 3-63
Joint cover ASSY
Hook D
Hook C
Taptite bind B M4x12
Taptite bind B M4x12
Hook A
Hook B
Taptite bind
B M4x12

Brother MFC-L2713DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 2400 x 600 dpi
Automatic Duplex Printing	Yes
Paper Input Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 15, 000 pages
Memory	64 MB
Processor	600 MHz
Scan Resolution	Up to 1200 x 1200 dpi
Fax Speed	33.6 kbps
Dimensions	410 x 398.5 x 318.5 mm
Weight	11.8 kg
Print Speed	30 ppm
Display	2-line LCD
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
