 Paper jam at the MP tray
<User Check>
• Check that the paper is set in the MP tray correctly.
• Flip over the paper in the MP tray or rotate the paper 180°.
• Adjust each paper guide according to each paper size.
• Check that there is not too much paper set.
• Check that the thickness of the paper is 60 to 230 g/m
2
.
• Flip through the paper and reset it in the MP tray.
Step Cause Remedy
1
Foreign object around the MP
tray
Remove the foreign object.
2
Connection failure of the MP
paper empty/registration front
sensor harness
Reconnect the MP paper empty/
registration front sensor harness.
3
MP registration front actuator
coming off
Reattach the MP registration front
actuator.
4
Connection failure of the
registration clutch harness
Reconnect the registration clutch harness.
5 Paper feed motor failure Replace the paper feed motor.
6
Damaged gears in the MP paper
feed system
Replace the frame L unit.
7 Damaged fuser unit Replace the fuser unit.
8 Main PCB failure Replace the main PCB ASSY.

Brother MFC-L2713DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 2400 x 600 dpi
Automatic Duplex Printing	Yes
Paper Input Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 15, 000 pages
Memory	64 MB
Processor	600 MHz
Scan Resolution	Up to 1200 x 1200 dpi
Fax Speed	33.6 kbps
Dimensions	410 x 398.5 x 318.5 mm
Weight	11.8 kg
Print Speed	30 ppm
Display	2-line LCD
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
