Page #89 background imageLoading...
Page #89 background image
2-49
Confidential
Error code 0501
The center thermistor of the fuser unit has not reached the specified temperature within the
specified time.
Error code 0502
The center thermistor of the fuser unit has not reached the specified temperature within the
specified time after it was heated normally to the certain level.
Error code 0503
The center thermistor of the fuser unit detected a temperature higher than the specified value.
Error code 0504
After the heat unit was heated normally, the center thermistor of the fuser unit detected a
temperature lower than the specified value.
Error code 0505
The center thermistor of the fuser unit detected a temperature rise greater than the specified
value within the specified time.
Error code 0506
The center thermistor of the fuser unit detected a temperature fall greater than the specified
value within the specified time.
Error code 0508
Temperature of the end part didn’t rise by 1 °C when the fuser unit heater was turned ON.
Error code 050A
The hardware detected a temperature error through the center thermistor or the side
thermistor of the fuser unit.
Error code 050B
When the center thermistor of the fuser unit was lower than the idle temperature, the side
thermistor detected a temperature higher than the specified temperature.
Error code 050C
When the center thermistor of the fuser unit was higher than the idle temperature, the side
thermistor detected a temperature lower than the specified temperature.
<User Check>
Turn OFF the power switch. After several seconds, turn ON the power again and check that
this error is reset.
Step Cause Remedy
1
Connection failure of the center
or side thermistor harness of the
fuser unit
Reconnect the center or side thermistor
harness of the fuser unit.
2
Connection failure of the heater
harness of the fuser unit
Reconnect the heater harness of the fuser
unit.
3
Connection failure of the eject
sensor PCB harness
Reconnect the eject sensor PCB harness.
4
Connection failure of the
low-
voltage power supply PCB harness
Reconnect the low-voltage power supply
PCB harness.
5 Eject sensor PCB failure Replace the eject sensor PCB ASSY.
6 Fuser unit failure Replace the fuser unit.
7
Low-voltage power supply PCB
failure
Replace the low-voltage power supply
PCB ASSY.
8 Main PCB failure Replace the main PCB ASSY.
