BRP Spyder RT - Page 170

SPECIFICATIONS
MODEL SPYDER RT
BRAKES
Type
Foot actuated, fully integrated hydraulic 3 wheel
braking system with ABS and EBD
Front brake
Dual rigid discs 270 mm (10.6 in), radially mounted
Brembo monobloc, with 4 piston calipers, 2-pad
Rear brake
Single disc 270 mm (10.6 in) with 1 piston floating
caliper with integrated parking brake
Capacity 530 ml (17.9 U.S. oz)
Brake fluid
Type DOT 4
Parking brake Mechanical, electrically actuated to the rear caliper
Minimum brake pad thickness 1 mm (.04 in)
Minimum brake disc thickness 6.4 mm (.25 in)
Maximum brake disc warpage 1mm (.039 in)
TIRES
Front KR31 165/55R15
Type (use only tires
recommended by BRP)
Rear KR21 225/50R15
Front
Nominal.: 103 kPa (15 PSI)
Min.: 89 kPa (13 PSI)
Max.: 117 kPa (17 PSI)
Nominal.: 193 kPa (28 PSI)
Min.: 179 kPa (26 PSI)
Max.: 207 kPa (30 PSI)
Pressure
Rear
NOTE: The pressure difference between the left and
right side tire should not exceed 3.4 kPa (.5 PSI).
Front 2.5 mm (3/32 in)
Minimum tire tread
depth
Rear 4 mm (5/32 in)
WHEELS
Front 381 mm (15 in) x 127 mm (5 in)
Size
(diameter X width)
Rear 381 mm (15 in) x 178 mm (7 in)
Front wheel nuts torque 90 N•m to 120 N•m (66 lbf•ft to 89 lbf•ft)
Rear drive axle nut torque 123 N•m to 137 N•m (91 lbf•ft to 101 lbf•ft)
