Bruker BCU05 - Figure 1.4. Heat Exchanger Support Stand (M151454 B)

12 (41) BRUKER BCU05 Version 006
BCU05 HR applications
Figure 1.4. Heat Exchanger support stand (M151454B)
3. Position the cooling unit as far as possible from the magnet so as to minimise
the effect of the magnet stray field.
valve
three way
main switch
support stand
BCU 05
heat exchanger
