15
standard backplate. The figure b elow shows the optional decorator backplate
installed with the standard backplate, described in Section 4.5.1.
A12214
NOTE: Once Evolution Control is secured to wall with the backplate assembly
(snapped together), care must be taken not to bend or break the interlocking tabs
when removing.
4.5.1. Decorati ve Backplate
Sold separately, a thin decorative backplate is available to hide any marks/screw
holes left from the previous thermostat. This decorative backplate (or beauty ring)
is used by snapping it onto the back of the mounting plate before securing the plate
to the wall.
A12213
