5 Job administration
It might be necessary to enter different measuring settings due to
the variety of materials and print images processed in the different
applications. With the sensor CLS Pro 600 you get the option to
save a relevant measuring parameter set, consisting of material
and/or job specific parameters, so-called Jobs. These jobs can be
called up whenever necessary. This enables you to set up repeat
jobs quickly and without any errors.
All of the basic settings necessary will be implemented when the
required job is selected. You only have to carry out the material
set-up (edge or line) for the work.
Certain basic jobs have already been pre-configured in the factory
and are available under the \\parameter\jobs\choose job\load
job menu.
The meanings of the pre-configured jobs are:
DEFAULT: Reset the default factory settings.
COLORED LINE: These settings are used when a colored line
has to be tracked and it lies in a field with
changing conditions.
SMALL LINES: These settings must be used if lines with a
width of less than 0.5 mm have to be
scanned.
STRICT CHECK: Select this setting if very constant measuring
and printing conditions are present,
regardless of whether there is a lot of noise
present in the field. In this case the system
will block it relatively quickly, but the danger
of latching on to contrast caused by noise is
minimal.
Use, for example, if there are large breaks in
the line (ratio between the broken and usable
signal > 20%).
VERY TOLERANT: Select this setting if extremely poor
measuring conditions are present (uneven
web running, changing print quality, etc.) but
no noise spikes. The number of blocking
actions undertaken will be kept to a minimum
in this case.
Use, for example, when the color of the edge
being scanned changes frequently or if the
print in alignment mode is uneven.
