SCAN ERROR Function
SMART MATRIX TWIST - 2-33 -
SCAN ERROR Function
This function allows you to display in real time the sensor positions detecting an error and the kind of error
detected by each sensor.
Enter the SCAN menu.
Select the SCAN ERROR menu item.
The display shows in real time the positions of the sensors
detecting an error and the kind of error for each position. In
this example the A1, A5, A6 sensors are detecting a
number of twists too low (Twist L) while the A2 sensor is
detecting a communication error (Err Com)
To go to the “Error Counter Display”
To go to the ”Sensor Histogram”
To exit the function
To go back to the menu.
SCAN
→
SCAN ERROR
