IS3x/TTS Sensor Features
SMART MATRIX TWIST - 3-10 -
Normal Operation = (the yarn runs normally and the number of twisting is within the
programmed range TPX MAX and TPX MIN)
Delay Control = Delay programmable via software
Failure Reset = Either Manual through (Touch Light) or Automatic if Reset Manual/Auto
parameter is set to Auto
CONT
PULSE 2S
PULSE 10S
Failure
Failure
Failure
10 seconds
2 seconds
