XT-70 Control Panel 71
[XT_INF_03] TERMINAL LABLE
[XT]
<Plenum T - reference only> <record index>
<Start - reference only> <record index>
<Outside T - reference only> <record index>
<Return T - reference only> <record index>
<Pile 1 - configurable>
<record index> AN5
<Pile 2 - configurable>
<record index> AN6
<Pile 3 - configurable>
<record index> AN7
<Pile 4 - configurable>
<record index> AN8
<Pile 5 - configurable>
<record index> AN9
<Pile 6 - configurable>
<record index> AN10
<Pile 7 - configurable>
<record index> AN11
<Pile 8 - configurable>
<record index> AN12
<Outside H - configurable>
<record index> H1
<Plenum H - configurable>
<record index> H2
<CO2 level - configurable>
<record index> H4
<Door Open - reference only> <record index>
<Operation Mode - reference only> <record index>
<Secondary Mode - reference only> <record index>
<Refrig Output - reference only> <record index>
<switch status 1 - reference only> <record index>
<switch status 2 - reference only> <record index>
<switch status 3 - reference only> <record index>
<output status - reference only> <record index>
<Return H - configurable>
<record index> H3
<Freq Drive Current - reference only> <record index>
<Daily Run - reference only> <record index>
<CPH - reference only> <record index>
<Pile T - reference only> <record index>
<Pile H - reference only> <record index>
<setpoint - reference only> <record index>
<target - reference only> <record index>
<CO2 SP - reference only> <record index>
<humid sp - reference only> <record index>
<cooling sp - reference only> <record index>
<refrig sp - reference only> <record index>
<timed sp - reference only> <record index>
The following shows the format of the CSV file. The sensors highlighted in yellow can be named. The
record index refers to the order in which the values will appear in the records. All record index fields
must have a value. If not being used, then insert a zero.
