XT-70 Control Panel 72
CSV Example:
[XT_INF_01]
[XT]
PLENUM T 4
START 5
OUTSIDE T 6
RETURN T 7
NE 8
NW 9
SE 10
SW 11
Middle E 12
Middle 13
Center 0
Unused 0
OSA H 14
PLEN H 15
CO2 17
DOOR OPEN 18
OPERATION MODE 1
SECONDARY MODE 2
REFRIG OUTPUT 19
SWITCH STATUS 1 20
SWITCH STATUS 2 0
SWITCH STATUS 3 0
OUTPUT STATUS 0
RTN H 16
FREQ DRIVE CURRENT 0
DAILY RUN 0
CPH 0
PILE T 0
PILE H 0
SETPOINT 3
TARGET 0
CO2 SP 0
HUMID SP 0
COOLING SP 0
REFRIG SP 0
TIMED SP 0
Highlighted names
can be changed to
any name you
want, with a ten
character maxi-
mum.
The numbers refer to the
order of the records. In this
example, the operation
mode will be the first value,
then the secondary mode,
setpoint and so on.
Max of 20 records
Timestamp OPERATION MODE SECONDARY MODE SETPOINT PLENUM T START OUTSIDE T
4/2/2009 0:00 WARMING 39.7 40.2 60.1 91.9
