BTX Gemini X2 - Preset Protocols; Using Preset Protocols

Gemini Series Electroporator User’s Manual
toll free 800.272.2775 • 508.893.8999 • www.btxonline.com
18
Using Preset Protocols
On the home screen, tap the Preset Protocols icon.
Double tap desired cell type.
Scroll through available cells.
Double tap desired cells.
Preset Protocols
Using Preset Protocols (continued)
Review parameters.
Tap Omega icon to measure pre pulse load resistance.
With load measurement OK press the Circle icon to run protocol.
Once protocol is complete, data regarding your pulse is displayed
and stored in the systems logs (BTX Gemini X2 only) for future use.
You may continue pulsing, go back to the protocol select screen,
or to the home screen.
PROTOCOL TYPEPROTOCOL SELECT
RUN
