29
Installation
Type 3280, 3285
Setting the DIP switch Type 3280
DIP switches
Control electronics
Figure 17: Location of the DIP switch, Type 3280
Setting the DIP switch Type 3285
DIP switches
Control electronics
Figure 18: Location of the DIP switch for Type 3285
→ DIP switch, set to “ON” or “OFF” depending on required function. To do this, carefully actuate the particular
DIP switch using a suitable tool.
ON 1
2
3
4
Figure 19: DIP switches
