TECHNICAL DATA
101 Integrated Amplifier
25
T D
Power amp
acoustic performance
Stereo: 2 x 120W (at 4Ω)
Input sensitivity:
1% THD + N
550 mV
Performance
frequency response
5 Hz – 60 kHz (-3 dB)
THD + N 0.015 %
Damping factor > 250
Signal-to-noise ratio
(power amp)
> 92 dB
Input impedance
XLR / RCA
16.4 kΩ / 8.2 kΩ
Inputs 3 balanced XLR/jack (combo), 2 unbalanced RCA
Amplification Variable
Preamp output Balanced XLR
Headphone output 6.3 mm, jack
Remote control Yes
Dimensions (W x H x D) 93 mm x 482 mm x 350 mm
(The length of the speaker terminals on the back side
and the connectors to be attached are not included in
the dimensions).
Weight Approx. 12 kg
Power consumption ON: max. 480 W
STBY: < 1 W
Subject to technical changes
