Burnham Revolution - SECTION AND WATER PIPING ASSEMBLY

83
Key
No.
Description
[Quantity] Part Number
RV3 RV4 RV5 RV6 RV7
1. SECTION AND WATER PIPING ASSEMBLY
1A Section Assembly, Complete
[1]
6170603
[1]
6170604
[1]
6170605
[1]
6170606
[1]
6170607
1A1 Left End Section [1] 7170601
1A2 Center Section
[1]
7171703
[2]
7171703
[3]
7171703
[4]
7171703
[5]
7171703
1A3 Right End Section [1] 71717021
1A4 Tie Rod, 1/4” -20
[2]
80861040
(9” Lg)
[2]
80861041
(12-1/2” Lg)
[2]
80861042
(15-1/2” Lg)
[2]
80861043
(19” Lg)
[2]
80861044
(22” Lg)
1A5 Hex Nut, 1/4” - 20, Heavy [4] 80860407
1A6 Slip Nipple, #3
[4]
806600009
[6]
806600009
[8]
806600009
[10]
806600009
[12]
806600009
1B Flue Gas Bafe
[2]
71106001
[3]
71106001
[4]
71106001
[5]
71106001
[6]
71106001
1C Temp / Pressure Gauge [1] 100282-03
1D Pipe Nipple, 1-1/4” x 4” [1] 806600028
1E Immersion Well, 1/2”, Honeywell 123869A [1] 80160456
1F Flanged Pipe Nipple [3] 6066045
1G Gasket [2] 8206056
1H 3/8” Steel Plain Flat Washer [16] 80860600
1J Tee, 1-1/4” x 1-1/4” x 3/4” [1] 806601109
1K Drain Valve, 3/4”, Conbraco 31-612-02 [1] 6066025
1L Water Manifold [1] 6066044
1M Circulator, Taco 007F, Position 4 [1] 8056107
1N Gasket, Circulator Flange, Taco ‘00’ Series [2] 806602006
1P Circulator Flange, 1-1/4” [2] 806602013
1Q Cap Screw, Hex Head, 7/16” - 14 x 1-1/2” [12] 80861301
1R Hex Nut, 7/16” - 14 [12] 80860406
