Burnham Revolution - Page 87

87
Key
No.
Description
[Quantity] Part Number
RV3 RV4 RV5 RV6 RV7
3. BASE ENCLOSURE ASSEMBLY
3A Base Tray [1] 71806032 [1] 71806042 [1] 71806052 [1] 71806062 [1] 71806072
3B Base Leg Assembly [6] 6186001
3B1 Base Leg [6] 71860021
3B2 Nylon Glide [6] 8186006
3C Base Wrapper [1] 71806033 [1] 71806043 [1] 71806053 [1] 71806063 [1] 71806073
3D
Burner Tray (1 Inch Main Burners) [1] 718600305 [1] 718600405 [1] 718600505 [1] 718600605 [1] 718600705
Burner Tray (40mm Main Burners) [1] 71806037 [1] 71806047 [1] 71806057 [1] 71806067 [1] 61806074
3E Base Rear Insulation [1] 72060035 [1] 72060045 [1] 72060055 [1] 72060065 [1] 72060075
3F Base Side Insulation [2] 720601
3G Enclosure Top Panel Assembly [1] 61806032 [1] 61806042 [1] 61806052 [1] 61806062 [1] 61806072
3H Base Front Panel Assembly [1] 61806031 [1] 61806041 [1] 61806051 [1] 61806061 [1] 61806071
3J Cover Plate, Manifold Seal [1] 71806002
3K Gasket, Manifold Seal [1] 8200603 [1] 8200604
3L Combustion Air Diffuser - Support [8] 80860603
3M Combustion Air Diffuser [1] 71806036 [1] 71806046 [1] 71806056 [1] 71806066 [1] 71806076
3N Burner Access Panel [1] 72106031 [1] 72106041 [1] 72106051 [1] 72106061 [1] 72106071
3P Flame Roll-Out Switch [1] 80160044
3Q
Flame Roll-Out Switch Mtg. Bracket 1”
[1] 7056018
[1] 71806005
Flame Roll-Out Switch Mtg. Bracket
40mm
-----
3R Enclosure Front Panel Assembly [1] 61806033 [1] 61806043 [1] 61806053 [1] 61806063 [1] 61806073
3R1 Enclosure Front Panel [1] 71806034 [1] 71806044 [1] 71806054 [1] 71806064 [1] 71806074
3R2 Observation Port Lens Retainer [1] 7186019
3R3 Observation Port Lens Gasket [2] 8206039
3R4 Observation Port Lens [1] 8026082
3S Fiberglass Tape Gasket, 1/8” x 1/2”
[112”]
9206075
[122”]
9206075
[132”]
9206075
[142”]
9206075
[152”]
9206075
3T Ceramic Fiber Gasket, 1/2” x 2”
[56”]
72017071
[62”]
72017071
[70”]
72017071
[76”]
72017071
[82”]
72017071
3U Self Tapping Screw, 1/4”-20 x 1/2” [25] 80860700
3V Sheet Metal Screw, #8 x 1/2” [24] 80860000
3W Sheet Metal Screw, #8 x 3/4” [3] 80860030
3X Self Tapping Screw, 5/16” -18 x 1-1/4” [4] 80860717
3Y Washer, 5/16” Flat [4] 80860601
3Z Lock Nut, 5/16” -18 [4] 80860464
3AA Silastic Sealant, RTV732, Silver [A/R] 9056024
3BB Silastic Sealant, RTV6500, Red [A/R] 9056060
3CC Jacket Lower Support Bar [1] 70406001
3DD Base Tray Support [1] 71806006
3EE Sheet Metal Screw, #10 -1/2” TRS Head [3] 80860005
