89
Key
No.
Description
[Quantity] Part Number
RV3 RV4 RV5 RV6 RV7
4. BURNER ASSEMBLIES
4A
Gas Valve (Natural Gas), Honeywell
VR8204C6000
[1] 81660176 -----
Gas Valve (Natural Gas), Honeywell
VR8304P4298
----- [1] 81660177
Gas Valve (LP Gas), Honeywell
VR8204C6018
[1] 81660180 -----
Gas Valve (LP Gas), Honeywell
VR8304P4280
----- [1] 81660181
4B
Nipple, 1/2” x 3” Lg. [1] 71806033 [1] 71806043 [1] 71806053 [1] 71806063 [1] 71806073
Nipple, 3/4” x 3” Lg. ------ [1] 806600002
4C
Union, 1/2” [1] 806604023 -----
Union, 3/4” ----- [1] 806604001
4D
1/2” Gas Manifold (1” Burner) [1] 82260036 [1] 82260046 [1] 82260056 -----
3/4” Gas Manifold (1” Burner) ----- ----- ----- [1] 82260066 [1] 82260076
1/2” Gas Manifold (40mm Burner) [1] 82260037 [1] 82260047 [1] 82260057 -----
3/4” Gas Manifold (40mm Burner) ----- ------ ----- [1] 82260067 [1] 82260077
4E
Main Burner Orices (1” Burner) Standard Altitude (0 - 2000 ft.)
#45 (Natural Gas) [3] 822711 [5] 822711 [7] 822711 [9] 822711 -----
#48 (Natural Gas) ----- ----- ----- ----- [12] 822726
#55 - Green (LP Gas) [3] 822708 [5] 822708 ----- ----- -----
1.25mm - Purple (LP Gas) ----- ----- [7] 822705 [9] 822705 -----
3/64” - Blue (LP Gas) ----- ----- ----- ----- [12] 822704
4E
Main Burner Orices (40mm Burner) High Altitude (2001 ft. - 5000 ft.)
#39 (Natural Gas) ----- [3] 822727 [4] 822727 [5] 822727 -----
#40 (Natural Gas) [2] 822728 ----- ----- ----- [6] 822728
#53 (LP Gas) [2] 822722 [3] 822722 [4] 822722 [5] 822722 [6] 822722
4E
Main Burner Orices (40mm Burner) High Altitude (5001 ft. - 9000 ft.)
#42 (Natural Gas) [2] 822730 ----- ----- ----- [6] 822730
#41 (Natural Gas) ----- [3] 822729 [4] 822729 [5] 822729 -----
#54 (LP Gas) [2] 822734 ----- ----- ----- -----
#53 (LP Gas) ----- [3] 822722 [4] 822722 [5] 822722 [6] 822722
4F
Pilot Assembly (Natural Gas) [1] 8236161
Pilot Assembly (LP Gas) [1] 8236162
4G
1” Burner w/Bracket [1] 8236098
40mm Burner w/Bracket [1] 8236136
4H
1” Burner [2] 8236099 [4] 8236099 [6] 8236099 [8] 8236099 [11] 8236099
40mm Burner [1] 8236135 [2] 8236135 [3] 8236135 [4] 8236135 [5] 8236135
4J
Pilot Tubing, Aluminum, 1/8” x 30” Lg. [1] 8236110 ----- -----
Pilot Tubing, Aluminum, 1/8” x 40” Lg. ----- [1] 8236100
4K
Machine Screw, #10-32 x 3/16” Lg.
(1” Burner)
[1] 80860874
Machine Screw, #10-32 x 3/16” Lg.
(40mm Burner)
[2] 80860874
4L Pilot Enclosure (40mm Burner) [1] 7230602
