BW Broadcast TX600 - Stereo Performance and Audio Processing; Program Inputs and Interfaces

!
10 - 2
RF Harmonic and
Spurious
Suppression
Meets or exceeds ETSI requirements
VSWR!operation!
Up to 1.5:1. Proportional foldback threshold from 1.5:1. Continued operation with
foldback to infinite VSWR. Protected against sudden short and open-circuit
conditions with mute to remove sustained arcing conditions, at all phase angles.
Environmental
Altitude
15,000 ft, 4,420m AMSL
Ambient
Temperature
Range
0 to +45ºC. Inlet air temperature must not exceed 45ºC at sea level, derated at
2ºC per 1000ft (300m) AMSL
Humidity
95%, non-condensing
Stereo Performance
Modes
Selectable: Stereo, Swap L/R, Mono L+R, Mono L, Mono R
Pre-emphasis
Selectable: 0, 50 or 75uS
Audio low-pass
filter
80dB at 19kHz
Stereo pilot tone
19kHz ±0.1Hz; injection level adjustable
38kHz, 57kHz,
76kHz, 95kHz
suppression
>70dB below ±75kHz deviation
Stereo separation
>80dB AES, >75dB analog 10Hz to 15kHz
Stereo signal to
noise ratio
>90dB AES, 86dB analog below 100% modulation at 400Hz; measured in 10Hz to
15kHz bandwidth with 75uS preemphasis and DIN 'A' weighting
Stereo total
harmonic
distortion
<0.03% THD+N, 10Hz to 15kHz, with 75uS deemphasis
Audio Processing
AGC stage
Wideband and four-band AGCs, with intelligent gating
Limiter stage
Four-band program-dependent limiter
Equalization
Parametric and shelf bass enhancement
Clipping
Multiband distortion-controlled, and compisite clipper with pilot protection
Processing modes
Multiple user-selectable presets
Program Inputs
Audio Inputs -
Digital
RJ45, 110 ohms balanced. Range -24dBFS to 0dBFS, up to 192kb/s, 16, 24, 32 bits
(MPX over AES ready)
Audio Inputs -
Digital
2 XLR, 10k ohms balanced. Range 0dBu to +15dBu max
Analog MPX
(composite) Inputs
2 BNC floating, unbalanced, 18k ohms. Range -10dBu to +12dBu max, can be
configured as MPX, SCA, RDS.
Analog MPX
(composite)
Outputs
2 BNC floating, unbalanced >600ohms. Range 0dBu to +12dBu max. Can be
configured as MPX, RDS or pilot outputs.
Internal RDS
generator
Dynamic RDS/RBDS generator.
Reference I/O
External 10MHz
clock input
BNC, unbalanced 50 ohms
