10 - 3
External 1PPS
clock input
BNC, unbalanced, 50 ohms TTL level
RF sample output
1 x SMC front panel -50dB. Not suitable for harmonic measurements
Remote I/O
Ethernet port
RJ45 100Mb/s ethernet/IP rear-panel for remote control
RS232
Telnet control
Parallel GPI/O
DB9 female standard remote control I/O with user-selectable command inputs
and status outputs active low, 5v 100mA.
Internal Options
FM Rebroadcast
Receiver
Input frequency range 87.5-108.0MHz, 50kHz steps. Dynamic multipath, noise and
control, FM Stereo Improvement. RDS PI code checking to prevent unauthorised
access.
Compliance
Compliance
standards
RoHS 2002/95/EC R&TTE 1999/5/EC
ETSI EN 60215 (Safety) ETSI EN 302 018 (ERM)
ETSI EN 300 384 (Radio)
FCC Part 73 (LPFM Type Acceptance
Industry Canada (IC)
!
