BYK-Gardner GmbH Hardware | 2
301 200 141 E 2401 wave-scan 3 ROBOTIC 11
The angle-deviation of the perpendiculars on the surface can amount to at most
to all sides.
NOTICE
The mounting can be done on the left or on the right side of the measurement
unit. The protruding element on the side not used can be screwed off (two small
screws).
2.3 Power Supply
The instrument is supplied by an external AC / DC power adapter, which is not
part of the delivery.
1
2
Illustration4: Interface connectors of wave-scan 3 ROBOTIC
1 Power supply is provided via a black 8-pole plug.
2 Data transmission is provided via a green 4-pole plug.
In order to connect the measuring instrument, first check the wiring and the
matching of the power supply. Subsequently you plug in the black plug and switch
on power.
