BYK wave-scan 3 Operating Manual

BYK-Gardner GmbH Hardware | 2
301 200 141 E 2401 wave-scan 3 ROBOTIC 9
2 Hardware
Before operating the instrument for the first time, please read the Operating In-
structions and take particular notice of the Safety Instructions. Unpack the in-
strument and check the delivery for completeness.
2.1 Delivery Content
The system comes complete with: Measurement unit, cover, test tile, certificate
and safety instructions. Also included are screws and a drawing for the robot
mounting board.
The items listed below are contained in the transportation case. Please contact
BYK-Gardner, if any item is missing or damaged. See also Delivery Notes [}28].
1
2
3
4
5
6
7
8
Illustration1: Delivery content
1 Safety instructions and retrace-
able certificate
5 Drawing for mounting board
2 Checking tile for instrument test 6 Cleaning towel for checking tile
3 Screws and tool for mounting
board
7 Measurement unit
4 USB cable type A / C for initializa-
tion
8 Protective cap
The power and communication cables - see Cabling [}13] - are outside the
transportation case, but inside the delivery packaging.
