5 Checking
Due to the underlying measurement principle, no calibration of the instrument is
required.
5.1 Principle
It is recommended, however, to check the functionality of the instrument at regu-
lar intervals (about once every 3 months). The reference tile included with delivery
is provided for this purpose.
Illustration24: Instrument and checking tile
5.2 Mounting
Mount the test tile near the robot at the position intended for the instrument test.
The robot is to be programmed to reach the checking tile.
1
2
3
4
Illustration25: Mounting of checking tile
1 Robot arm with rotable adapter
2 Instrument on rotable adapter
3 Car body / part in robot cell
4 Checking tile mounted to wall
