BYK wave-scan 3 Operating Manual

BYK-Gardner GmbH Cabling | 3
301 200 141 E 2401 wave-scan 3 ROBOTIC 17
The delivery comprises cables and connectors.
Lappkabel 2170894 4-wire Lappkabel 2170894 4-wire Lappkabel 2170888 4-wire
Phoenix
1411066
4-pol pins
M12-D
Phoenix
1411066
4-pol pins
M12-D
Phoenix
1411066
4-pol pins
M12-D
Phoenix
1411069
4-pol socket
M12-D
Phoenix
1411069
4-pol socket
M12-D
20 m on flor - oil resistant
301 200 149 301 200 148
10 m for track chain
301 200 147
8 m for robot - torsion capable
Lappkabel
21700605
RJ-45
Illustration12: 301 200 146 Data cable complete for 7410
Products from following vendors are used:
• https://www.binder-connector.com
• https://www.lappkabel.com
• https://www.phoenixcontact.com
