8 Configuration
With this function you can configure the system according to your needs. There are different
types provided to change the configuration of the system.
Click on icon Configuration. The configuration screens provide buttons for easy navigation.
The current settings can just be viewed or changed and saved.
1 2
3
Some options can be activated via a so-called toggle button. Some options can be configured
via a rotating menu. This menu is working like a wheel.
4
5
6
7
8
These options have following meaning.
1 Back: Go back to previous screen. 2 Cancel: Go back to previous screen
without saving.
3 Accept: Go back to the previous screen
and save your changes.
4 Active: Option is activated. Click left to
deactivate.
5 Inactive: Option is deactivated. Click
right to activate.
6 Wheel: Tap an entry in the menu and
move it to the left or to the right.
7 Left: One step to the left moves the
wheel to next value.
8 Right: One step to the right moves the
wheel to previous value.
