C-COR.net FlexNet E7 - Measured Signal Information; Power Supply Information

E-2 FlexNet
®
700 Series Line Extender Rev F
E
Measured Signal Information
Power Supply Information
Power Supply Type
Forward Signal Levels Reverse Signal Levels
Tes tp o in t
Forward
High Carrier
Forward
Low Carrier
Te s tpo int
Reverse
High Carrier
Reverse
Low Carrier
P1 (input) P1 (output)
P3 (dist output) P3 (input)
Internal TP
(MAN)
Internal TP
(ALC/TLC Active)
Fuse Values Voltages
MAIN FUSE AC Volts Raw DC
THRU
POWER
FUSE B+ Ripple
Reverse B+
