Table C.3 SEQ-750 Series Cable Equalizers
dB of cable
equalized at
highest
frequency
Insertion Loss in dB at Frequency (MHz)
Model Number 54 70 80 222 350 450 550 650 750
SEQ-750-02 2.0 2.0 2.0 1.8 1.4 1.3 1.3 1.2 1.0 1.5
SEQ-750-03 3.0 2.8 2.7 2.4 1.9 1.7 1.5 1.3 1.0 2.5
SEQ-750-04 3.9 3.9 3.8 3.1 2.4 2.0 1.7 1.4 1.0 4.0
SEQ-750-05 4.9 4.6 4.5 3.5 2.9 2.3 1.8 1.4 1.0 5.0
SEQ-750-06 5.9 5.7 5.6 4.2 3.3 2.7 2.0 1.5 1.0 6.5
SEQ-750-07 7.0 6.8 6.6 5.0 3.6 2.8 2.0 1.6 1.0 8.0
SEQ-750-08 8.0 7.9 7.6 5.5 4.2 3.3 2.5 1.8 1.0 9.0
SEQ-750-09 9.0 8.8 8.6 6.3 4.8 3.8 2.7 2.0 1.0 10.5
SEQ-750-10 9.8 9.4 9.2 6.7 5.0 3.8 2.8 2.0 1.0 12.0
SEQ-750-11 11.0 10.5 10.2 7.5 5.5 4.2 3.0 2.0 1.0 13.5
SEQ-750-12 11.8 11.3 11.0 8.1 6.0 4.6 3.3 2.2 1.0 14.5
SEQ-750-13 12.9 12.4 12.2 8.9 6.6 5.1 3.7 2.5 1.0 16.0
SEQ-750-14 14.0 13.5 13.2 9.7 6.9 5.3 3.8 2.5 1.0 17.0
SEQ-750-15 14.9 14.3 13.9 10.1 7.5 5.8 4.3 2.6 1.0 18.5
SEQ-750-16 15.8 14.9 14.5 10.5 8.0 6.1 4.4 2.7 1.0 20.0
SEQ-750-17 16.8 16.0 15.6 11.3 8.2 6.2 4.4 2.6 1.0 21.0
SEQ-750-18 17.9 17.1 16.6 11.9 8.6 6.6 4.6 2.6 1.0 22.4
SEQ-750-19 18.8 17.8 17.4 12.3 9.1 6.9 4.8 2.7 1.0 23.7
SEQ-750-20 19.8 19.0 18.5 13.2 9.5 7.2 5.0 2.8 1.0 25.0
SEQ-750-21 20.8 19.8 19.3 13.4 10.0 7.5 5.2 2.9 1.0 26.3
SEQ-750-2-2 2.8 2.8 2.8 2.5 2.3 2.2 2.1 2.1 2.0 1.1
SEQ-750-4-2 4.5 4.4 4.3 3.6 3.1 2.8 2.5 2.2 2.0 3.3
SEQ-750-4-3 5.5 5.4 5.3 4.7 4.1 3.8 3.5 3.2 3.0 3.3
SEQ-750-5-5 8.9 8.6 8.6 7.6 6.9 6.3 5.8 5.4 5.0 5.0
Passband Flatness: ±0.3 dB Document number: 600563 Rev H
Return Loss I/O: 18/16 dB
