C-8 FlexNet
®
700 Series Line Extender Rev F
C
Table C.4 SCS-750 Series Cable Simulators
Insertion Loss in dB at Frequency (MHz) dB of cable simulated at
Model Number 54 70 80 222 350 450 550 650 750 350 450 550 650 750
SCS-750-02 1.0 1.0 1.0 1.3 1.5 1.6 1.7 1.8 1.8 0.7 0.8 0.9 1.0 1.1
SCS-750-03 1.0 1.0 1.0 1.6 2.0 2.2 2.4 2.6 2.8 1.5 1.7 1.9 2.1 2.3
SCS-750-04 1.0 1.0 1.1 1.9 2.4 2.7 3.0 3.3 3.5 2.2 2.5 2.8 3.0 3.3
SCS-750-05 1.0 1.1 1.2 2.3 3.0 3.4 3.9 4.3 4.6 3.2 3.6 4.0 4.4 4.8
SCS-750-06 1.0 1.1 1.3 3.1 3.9 4.5 5.1 5.7 6.2 4.6 5.2 5.8 6.4 7.0
SCS-750-07 1.0 1.1 1.3 3.3 4.2 4.9 5.6 6.2 6.8 5.0 5.7 6.4 7.0 7.6
SCS-750-08 1.0 1.1 1.5 3.4 4.7 5.6 6.3 7.1 7.8 5.9 6.7 7.5 8.2 9.0
SCS-750-09 1.0 1.2 1.5 4.0 5.4 6.4 7.3 8.2 9.0 6.9 7.9 8.8 9.7 10.5
SCS-750-10 1.0 1.2 1.5 4.1 5.7 6.7 7.7 8.7 9.5 7.4 8.4 9.4 10.4 11.2
SCS-750-11 1.0 1.2 1.5 4.3 6.4 7.6 8.7 9.8 10.7 8.4 9.6 10.7 11.9 12.8
SCS-750-12 1.1 1.6 2.0 5.1 7.0 8.3 9.5 10.7 11.8 9.4 10.7 11.9 13.2 14.2
SCS-750-13 1.1 1.6 2.0 5.4 7.5 8.9 10.2 11.6 12.7 10.1 11.6 12.9 14.3 15.4
SCS-750-14 1.1 1.6 1.7 5.7 8.2 9.8 11.3 12.8 14.1 11.3 12.9 14.4 15.9 17.2
SCS-750-15 1.1 1.6 1.7 5.8 8.7 10.4 12.0 13.6 15.0 12.1 13.8 15.4 17.0 18.4
Passband Flatness: 0.6 dB, P-V Document number: 600647 Rev B
Return Loss I/O: 18/16 dB
Table C.5 SEQ-625 Series Cable Equalizers
dB of cable
equalized at
highest
frequency
Insertion Loss in dB at Frequency (MHz)
Model Number 54 70 80 222 350 450 550 600 625
SEQ-625-02 1.9 1.8 1.8 1.5 1.4 1.2 1.1 1.0 1.0 1.3
SEQ-625-03 2.9 2.8 2.7 2.1 1.7 1.4 1.2 1.1 1.0 2.7
SEQ-625-04 3.8 3.7 3.6 2.7 2.1 1.7 1.3 1.1 1.0 4.0
SEQ-625-05 4.8 4.6 4.5 3.4 2.5 1.9 1.4 1.1 1.0 5.4
SEQ-625-06 5.8 5.5 5.3 3.6 2.8 2.1 1.5 1.1 1.0 6.7
SEQ-625-07 6.8 6.4 6.2 4.4 3.2 2.3 1.5 1.2 1.0 8.0
SEQ-625-08 7.8 7.4 7.2 5.1 3.5 2.5 1.6 1.2 1.0 9.4
SEQ-625-09 8.8 8.4 8.1 5.6 3.9 2.8 1.7 1.2 1.0 10.7
SEQ-625-10 9.8 9.3 8.9 6.1 4.3 3.0 1.8 1.3 1.0 12.1
SEQ-625-11 10.7 10.2 10.0 6.9 4.6 3.2 1.9 1.3 1.0 13.4
SEQ-625-12 11.6 11.0 10.6 7.3 5.0 3.4 2.0 1.3 1.0 14.7
SEQ-625-13 12.7 12.1 11.7 8.2 5.4 3.6 2.1 1.4 1.0 16.1
SEQ-625-14 13.9 13.2 12.8 8.8 5.7 3.9 2.2 1.4 1.0 17.4
SEQ-625-15 14.6 13.8 13.4 9.1 6.1 4.1 2.3 1.4 1.0 18.8
SEQ-625-16 15.7 14.9 14.5 10.0 6.4 4.3 2.4 1.4 1.0 20.1
SEQ-625-17 16.7 15.9 15.4 10.4 6.8 4.5 2.5 1.5 1.0 21.4
SEQ-625-18 17.5 16.6 16.1 10.8 7.2 4.7 2.5 1.5 1.0 22.8
SEQ-625-19 18.5 17.5 17.0 11.5 7.5 5.0 2.6 1.5 1.0 24.1
Passband Flatness: 0.4dB, P-V Document number: 600911 Rev B
Return Loss I/O: 18/16dB
