Rev F Housing Instructions 3-3
3
Figure 3.2
Housing Inspection
(Inside)
5. Before closing the housing:
a. The housing may be mounted with or without the RF module installed. Cable
attachment may be easier without a module installed. Refer to RF Module
Replacement on page 6-2 beginning with Step 4 for instructions on installing an RF
module.
b. If desired, install plug-in accessories. Installing accessories at this point is often more
convenient than after the housing is mounted. Accessory values can be found on
system maps.
6. Close the housing. Refer to Housing Closing and Tightening on page 3-16, for instructions.
Flat Lid Housing Full Lid Housing
Rubber
Gasket
Mesh
Gasket
Port 3Port 1Port 3Port 1
