Rev F Reference Tables C-9
C
Table C.6 MEQ-550 and MEQT-550 Series Cable Equalizers
dB of cable
equalized at
highest
frequency
Insertion Loss in dB at Frequency (MHz)
Model Number 54 70 80 222 300 400 450 500 550
MEQ-550-02 2.0 2.0 1.9 1.4 1.4 1.2 1.1 1.1 1.0 1.4
MEQ-550-03 3.0 3.0 3.0 2.2 1.8 1.4 1.3 1.1 1.0 2.8
MEQ-550-04 4.0 3.9 3.7 2.6 2.2 1.7 1.4 1.2 1.0 4.2
MEQ-550-05 4.9 4.5 4.4 3.1 2.6 1.9 1.6 1.3 1.0 5.6
MEQ-550-06 5.9 5.6 5.5 3.7 2.9 2.1 1.7 1.3 1.0 6.9
MEQ-550-07 6.9 6.5 6.3 4.0 3.3 2.3 1.9 1.4 1.0 8.3
MEQ-550-08 7.8 7.4 7.1 4.7 3.7 2.6 2.0 1.5 1.0 9.7
MEQ-550-09 8.9 8.4 8.1 4.6 4.1 2.8 2.2 1.6 1.0 11.1
MEQ-550-10 9.8 9.3 9.1 6.1 4.5 3.0 2.3 1.6 1.0 12.5
MEQ-550-11 10.8 10.2 9.9 6.0 4.9 3.2 2.4 1.7 1.0 13.9
MEQ-550-12 11.7 11.1 10.7 6.6 5.3 3.5 2.6 1.8 1.0 15.3
MEQ-550-13 12.7 12.0 11.5 7.1 5.7 3.7 2.7 1.8 1.0 16.7
MEQ-550-14 13.8 13.0 12.6 7.8 6.1 3.9 2.9 1.9 1.0 18.1
MEQ-550-15 14.6 14.0 13.5 8.8 6.5 4.1 3.0 2.0 1.0 19.5
MEQ-550-16 15.3 14.5 14.1 9.0 6.8 4.3 3.2 2.0 1.0 20.8
MEQ-550-17 16.7 15.9 15.4 10.3 7.3 4.6 3.3 2.1 1.0 22.2
MEQ-550-18 17.5 16.8 16.3 10.4 7.7 4.8 3.5 2.2 1.0 23.6
MEQT-550-4 7.0 6.9 6.8 5.3 4.5 3.9 3.7 3.4 3.0 5.5
MEQT-550-8 10.9 6.8 6.6 5.3 6.1 4.8 4.1 3.7 3.0 11.1
MEQT-550-11 13.7 13.0 12.7 8.9 7.2 5.4 4.6 4.0 3.0 15.2
Passband Flatness: MEQ-550 (-02 thru -09): 0.3 dB, P-V MEQ-550 Document number: 600564 Rev B
MEQ-550 (-10 thru -18): 0.4 dB, P-V MEQT-550 Document number: 600600 Rev B
MEQT-550: 0.4 dB, P-V
Return Loss I/O: 18/16 dB
Table C.7 MCS-550 Series Cable Simulators
Insertion Loss in dB at Frequency (MHz) dB of cable simulated at
Model Number 50 150 300 330 400 450 500 550 300 330 400 450 500 550
MCS-550-2 1.0 1.3 1.6 1.7 1.8 1.8 1.9 2.0 1.0 1.1 1.2 1.2 1.3 1.4
MCS-550-3 1.0 1.6 2.2 2.3 2.5 2.7 2.8 3.0 2.0 2.1 2.3 2.5 2.6 2.8
MCS-550-4 1.0 1.9 2.8 3.0 3.3 3.5 3.8 4.0 3.0 3.2 3.5 3.7 4.0 4.2
MCS-550-5 1.0 2.2 3.4 3.6 4.1 4.4 4.7 5.0 4.0 4.2 4.7 5.0 5.3 5.6
MCS-550-6 1.0 2.4 4.0 4.3 4.9 5.2 5.6 6.0 5.0 5.3 5.8 6.2 6.6 6.9
MCS-550-7 1.0 2.8 4.6 4.9 5.6 6.1 6.5 7.0 6.0 6.4 7.0 7.5 7.9 8.3
MCS-550-8 1.0 3.0 5.2 5.6 6.4 6.9 7.5 8.0 7.0 7.4 8.2 8.7 9.2 9.7
MCS-550-9 1.0 3.3 5.8 6.3 7.2 7.8 8.4 9.0 8.0 8.4 9.3 10.0 10.6 11.1
Passband Flatness: 0.4 dB, P-V Document number: 600569 Rev 50
Return Loss I/O: 18/16 dB
