C-10 FlexNet
®
700 Series Line Extender Rev F
C
Table C.8 MEQ-65 and MEQT-65 Series Cable Equalizers
Insertion Loss in dB at
Frequency (MHz)
dB of cable equalized at
Model Number 5 65 65 300 400 450 550 750
MEQ-65-02 2.0 1.0 1.3 3.0 3.5 3.7 4.2 5.0
MEQ-65-03 2.9 1.0 2.7 6.0 7.0 7.5 8.3 9.9
MEQ-65-04 3.9 1.0 4.0 9.0 10.5 11.2 12.5 14.9
MEQ-65-05 5.2 1.0 5.8 13.0 15.2 16.2 18.1 21.5
MEQ-65-06 6.2 1.0 7.1 16.0 18.7 19.9 22.2 26.5
MEQ-65-07 7.1 1.0 8.5 19.0 22.2 23.6 26.4 31.5
MEQT-65-02 4.4 2.5 2.7 6.0 7.0 7.5 8.3 9.9
MEQT-65-03 5.4 2.5 4.0 9.0 10.5 11.2 12.5 14.9
MEQT-65-04 6.7 2.5 5.8 13.0 15.2 16.2 18.1 21.5
MEQT-65-05 7.7 2.5 7.1 16.0 18.7 19.9 22.2 26.5
MEQT-65-06 8.6 2.5 8.5 19.0 22.2 23.6 26.4 31.5
MEQT-65-07 9.6 2.5 9.8 22.0 25.7 27.4 30.6 36.4
Passband Flatness: MEQ-65 (±0.1dB) MEQ-65 Document number: 600615 Rev B
MEQT-65 (±0.2dB) MEQT-65 Document number: 600616 Rev B
Return Loss I/O: 18/16dB
Table C.9 MEQ-55 and MEQT-55 Series Cable Equalizers
Insertion Loss in dB at
Frequency (MHz)
dB of cable equalized at
Model Number 5 55 55 300 400 450 550 750
MEQ-55-2 1.9 1.0 1.2 3.0 3.5 3.7 4.2 5.0
MEQ-55-3 2.7 1.0 2.5 6.0 7.0 7.5 8.3 9.9
MEQ-55-4 3.6 1.0 3.7 9.0 10.5 11.2 12.5 14.9
MEQ-55-5 4.5 1.0 4.9 12.0 14.0 14.9 16.7 19.9
MEQ-55-6 5.6 1.0 6.6 16.0 18.7 19.9 22.2 26.5
MEQ-55-7 6.8 1.0 8.2 20.0 23.4 24.9 27.8 33.1
MEQT-55-2 4.2 2.5 2.5 6.0 7.0 7.5 8.3 9.9
MEQT-55-3 5.1 2.5 3.7 9.0 10.5 11.2 12.5 14.9
MEQT-55-4 6.0 2.5 4.9 12.0 14.0 14.9 16.7 19.9
MEQT-55-5 7.1 2.5 6.6 16.0 18.7 19.9 22.2 26.5
MEQT-55-6 8.3 2.5 8.2 20.0 23.4 24.9 27.8 33.1
MEQT-55-7 9.5 2.5 9.9 24.0 28.0 29.9 33.3 39.8
Passband Flatness: 0.2dB, P-V MEQ-55 Document number: 600695 Rev 50
Return Loss I/O: 18/16dB MEQT-55 Document number: 600696 Rev 50
