Rev F Reference Tables C-11
C
Table C.10 MEQ-42 and MEQT-42 Series Cable Equalizers
Insertion Loss in dB at
Frequency (MHz)
dB of cable equalized at
Model Number 5 42 42 300 400 450 550 750
MEQ-42-2 3.0 1.0 3.0 8.0 9.4 10.2 11.3 13.4
MEQ-42-3 4.0 1.0 4.6 12.6 15.0 15.8 17.7 21.0
MEQ-42-4 5.0 1.0 6.1 16.7 19.4 20.7 23.0 27.0
MEQ-42-5 6.0 1.0 7.6 20.4 23.8 25.4 28.3 33.0
MEQ-42-6 7.0 1.0 9.1 24.6 29.0 30.4 34.0 39.6
MEQ-42-7 8.0 1.0 10.6 27.0 31.5 33.0 36.4 45.5
MEQT-42-2 3.6 2.5 3.2 9.0 10.5 11.2 12.5 14.9
MEQT-42-3 5.6 2.5 4.7 13.0 15.2 16.2 18.1 21.5
MEQT-42-4 6.8 2.5 6.5 18.0 21.0 22.4 25.0 29.8
MEQT-42-5 8.4 2.5 9.0 25.0 29.2 31.1 34.7 41.4
MEQT-42-6 8.7 2.5 9.4 26.0 30.4 32.4 36.1 43.1
MEQT-42-7 10.1 2.5 11.5 32.0 37.4 39.8 44.5 53.0
Passband Flatness: 0.2dB, P-V MEQ-42 Document number: 600540 Rev C
0.3dB, P-V MEQT-42 Document number: 600595 Rev D
Return Loss I/O: 18/16 dB
Table C.11 MEQ-33 and MEQT-33 Series Cable Equalizers
Insertion Loss in dB
at Frequency (MHz)
dB of cable equalized at
Model Number 5 33 33 300 400 450 550 750
MEQ-33-2 2.3 1.0 2.2 7.0 8.2 8.7 9.7 11.6
MEQ-33-3 3.1 1.0 3.5 11.0 12.8 13.7 15.3 18.2
MEQ-33-4 3.8 1.0 4.5 14.0 16.4 17.4 19.4 23.2
MEQ-33-5 5.1 1.0 6.7 21.0 24.5 26.1 29.2 34.8
MEQ-33-6 6.5 1.0 8.9 28.0 29.5 34.8 38.7 46.4
MEQ-33-7 7.5 1.0 10.5 33.0 38.5 41.0 45.8 54.7
MEQT-33-02 4.7 2.5 3.5 11.0 12.8 13.7 15.3 18.2
MEQT-33-03 5.3 2.5 4.5 14.0 16.4 17.4 19.4 23.2
MEQT-33-04 6.6 2.5 6.7 21.0 24.5 26.1 29.2 34.8
MEQT-33-05 7.8 2.5 8.9 28.0 29.5 34.8 38.9 46.4
MEQT-33-06 9.0 2.5 10.5 33.0 38.5 41.0 45.8 54.7
MEQT-33-07 9.6 2.5 11.5 36.0 42.0 44.8 50.0 59.6
Passband Flatness: 0.2 dB, peak to valley MEQ-33 Document number: 600598 Rev B
Return Loss I/O: 18/16 dB MEQT-33 Document number: 600686 Rev A
