C-12 FlexNet
®
700 Series Line Extender Rev F
C
Table C.12 MEQ-30 AND MEQT-30 Series Cable Equalizers
Insertion Loss in dB at
Frequency (MHz)
dB of cable equalized at
Model Number 5 30 30 300 450 550 750
MEQ-30-2 3.1 1.0 3.4 11.0 13.7 15.3 18.2
MEQ-30-3 3.9 1.0 4.9 16.0 19.9 22.2 26.5
MEQ-30-4 4.8 1.0 6.4 21.0 26.1 29.2 34.8
MEQ-30-5 5.5 1.0 7.6 25.0 31.1 34.7 41.4
MEQ-30-6 6.4 1.0 8.9 29.0 36.1 40.3 48.0
MEQ-30-7 7.1 1.0 10.1 33.0 41.1 45.8 54.7
MEQT-30-2 5.1 2.5 4.3 14.0 17.4 19.4 23.2
MEQT-30-4 6.3 2.5 6.4 21.0 26.1 29.2 34.8
MEQT-30-6 7.6 2.5 8.5 28.0 34.8 38.9 46.4
Passband Flatness: MEQ-30: 0.2 dB, p-v MEQ-30 Document number: 600597 Rev A
MEQT-30: 0.4 dB, p-v MEQT-30 Document number: 600599 Rev A
Return Loss I/O: 18/16 dB
Table C.13 SEQPB Series Cable Attenuators (PADs)
Model Number 5-1000 MHz Flat Loss (dB)
SEQPB-01 1.0
SEQPB-1.5 1.5
SEQPB-02 2.0
SEQPB-03 3.0
SEQPB-04 4.0
SEQPB-05 5.0
SEQPB-06 6.0
SEQPB-07 7.0
SEQPB-08 8.0
SEQPB-09 9.0
SEQPB-10 10.0
Passband Flatness: ±0.3dB Document number: 600668 Rev F
Return Loss: 19dB (SEQPB-01 to SEQPB-06)
18.5dB (SEQPB-07, SEQPB-10)
Slope: -0.2 to -0.7dB
