Rev F Introduction 1-7
1
Materials
Fixed Slope Feed through
(MEQ Stripline)
Zero slope adjustment (P/N MEQ-550-0) Line extender alignment if EQ
jumpers are cut
Fixed Attenuator Feed
through (PAD Stripline)
Zero gain adjustment (P/N SPB-0) Line extender alignment if PAD
jumpers are cut
Return Upgrade Kit (See Table 4.5) Return kit installation
Clamps and Bolts C-COR, HB0214 or HB0216
(Supplied with the line extender)
Line extender installation
1/4-20 UNC bolts, washers,
and shims
—Wall mounting
Two diplex filters P/N 162198-01 Return kit installation in E629
Extension Mounting Brackets
(EMBs)
3.2 or 6 inch (8 or 15cm) length with
mounting hardware (P/Ns 172187-01 and
172187-03)
Installation application
Thermal Joint Compound — Return kit installation
1. An 11 mm nutdriver or wrench can normally be used in place of a 7/16-inch tool if the bolt and nutdriver are
manufactured to nominal “across the flat” tolerances. A non-fit can occur if the nutdriver is manufactured to
minimum dimensions and the bolt head to maximum dimensions.
Table 1.2 Tools and Materials
Tools/Materials Required Characteristic Use
