Rev F Housing Instructions 3-9

3

Figure 3.6

Wall/ Mounting with

Wall Mount Bosses

Wall

Flat Washer

Mounting Bolt

Wall Mount

Boss

Lock Washer

9.0 in.

(22.86cm)

Wall Mount Bosses
