Table A.1 E7 Line Extender RF Module Specifications
1
1. The listed characteristics are for current and previous models. Some models and characteristics may no longer
be available. Contact your C-COR sales representative for specific information.
Characteristic E75D E77D
2
(117V)
2. To reduce the risk of fire or electrical shock, do not expose this appliance to rain or moisture.
E70C E71C E72C E73C E73C
2
(117V)
E729 E629A
Bandwidth
(MHz)
862 862 750 750 750 750 750 550 550
Spacing 32dB 35dB 21dB 28dB 30dB 33dB 33dB 30/31dB 32dB
Level Control ALC NLC ALC ALC ALC,
TLC
none none none,
ALC
none
Return 20dB none,
passive,
20dB
none, passive,
18dB
none, passive, 18
or 20dB
20dB none,
passive,
18 or
20dB
none
Input/output
configuration
1 input, 1 output
Testpoints –25dB loss (for balancing the forward RF path)
Power Passing 10A maximum continuous current for units with 60VAC Supplies; 13A for 90VAC and 117VAC
Supplies
Operating
Temperature
Range
–40 to +140°F (–40 to +60°C)
ALC = Automatic level control
TLC = Thermal level control
NLC = No level control
passive = no amplification (11dB loss) (5dB loss for E77 passive)
18dB = active standard return gain
20dB = active high return gain
