C-more micro EA1-S6ML User Manual

Cables from AutomationDirect - Wiring Diagrams (cont’d)
GE:
Mitsubishi:
Mitsubishi FX Series 25-pin D-sub port,
RS-422A (p/n EA-MITSU-CBL)
To PLC
25-Pin Port
25-pin
D-sub
(male)
Wiring Diagram
Note: Use the above wiring diagram if you need to make your own cable. We recommend Belden 8103 shielded cable or equivalent.
1
25
25 = do not use
24 = do not use
23 = do not use
22 = do not use
21 = do not use
20 = do not use
19 = do not use
18 = do not use
17 = do not use
16 = SD– (RS422)
15 = RD– (RS422)
14 = do not use
13 = do not use
12 = do not use
11 = do not use
10 = do not use
9 = do not use
8 = do not use
7 = Signal GND
6 = do not use
5 = do not use
4 = Signal GND
3 = SD+ (RS422)
2 = RD+ (RS422)
1 = do not use
3
16
7
SD+
SD–
GND
9
10
5
1
RD+
RD–
shield
RD+
RD–
2
15
11
12
SD+
SD–
Term.
13
8 = do not use
7 = do not use
6 = do not use
5 = Logic GND
4 = do not use
3 = do not use
2 = do not use
1 = Frame GND
15 = do not use
14 = do not use
13 = Termination
12 = SD– (RS422)
11 = SD+ (RS422)
10 = RD– (RS422)
9 = RD+ (RS422)
1
15
15-pin
D-sub
(male)
4
GND
To C-more Micro-Graphic
Serial Port2
EA-MITSU-CBL
6–24
Chapter 6: PLC Communications
6
®
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
GE 90/30, 90/70, Micro 90 and VersaMax Micro (Port 2)
15-pin D-sub port, RS-422A (p/n EA-90-30-CBL)
To PLC
15-Pin Port
Wiring Diagram
Note: Use the above wiring diagram if you need to make your own cable. We recommend Belden 8103 shielded cable or equivalent.
13
12
7
SD(B)
SD(A)
GND
9
10
5
1
RD+
RD–
shield
RD(B’)
RD(A’)
11
10
11
12
SD+
SD–
Term.
13
8 = do not use
7 = do not use
6 = do not use
5 = Logic GND
4 = do not use
3 = do not use
2 = do not use
1 = Frame GND
15 = do not use
14 = do not use
13 = Termination
12 = SD– (RS422)
11 = SD+ (RS422)
10 = RD– (RS422)
9 = RD+ (RS422)
1
15
15-pin
D-sub
(male)
8
15
5
8 = CTS(B’)
7 = Logic GND
6 = do not use
5 = +5V
4 = do not use
3 = do not use
2 = do not use
1 = do not use
15 = CTS(A’)
14 = do not use
13 = SD(B)
12 = SD(A)
11 = RD(B’)
10 = RD(A’)
9 = do not use
1
15
15-pin
D-sub
(male)
CTS(B’)
CTS(A’)
+5V
To C-more Micro-Graphic
Serial Port2
EA-90-30-CBL
