EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Model Specifications (cont’d)
Specifications (cont’d)
Screen Objects:
• Functional Devices
Push Button, Switch, Indicator Button, Indicator Light, Graphic Indicator Light, Numeric
Display, Numeric Entry, Inc/Dec Value, Bar Graph, Bitmap Button, Static Bitmap, Dynamic
Bitmap, Recipe Button, Static Text, Lookup Text, Dynamic Text, Screen Change Push Button,
Screen Selector, Adjust Contrast, Function, Key Configuration Object, Real Time Graph,
Line Graph, Analog Meter.
• Static Shapes
Lines, Rectangles, Circles and Frames
• Displayable Fonts
Fixed fonts: 6x6, 6x8, 8x16, 16x16, 32x16, 32x32, and Windows fonts
Electrical:
Low Power Mode High Power Mode
• Input Voltage Range
5.0 VDC (4.75 – 5 25 VDC) 12/24 VDC (10.2 – 26.4 VDC)
• Input Power
Supplied through the panel’s RJ12 serial
communications port connection when used
with most AutomationDirect PLCs having a
RJ12 communication port or from a PC during
programming.
Supplied from an external 12-24 VDC power
source
• Power Consumption
1.05 W @ 5 VDC (210 mA)
6.5 W @ 10.2 VDC (630 mA),
12 VDC (540 mA), 24 VDC (250 mA)
• Recommended Fuse
No fuse required when directly connected to a
PLC or PC with recommended cable.
Type AGC fast acting glass fuse,
750 mA, 250 VAC, ADC p/n AGC-75
• Max. Inrush Current
1 A for 500 µs 10 A for 500 µs
• Acceptable External
Power Drop
Maximum 1 ms
Environmental:
• Operating Temperature
0 to 50 °C (32 to 122 °F)
• Storage Temperature
–20 to +60 °C (–4 to +140 °F)
• Humidity
5–95% RH, non-condensing
• Environmental Air
No corrosive gases permitted
• Vibration
IEC60068-2-6 (Test Fc), 5-9 Hz: 3.5 mm amplitude, 9-150 Hz: 1.0G, sweeping, at a rate of
1 octave/min. (±10%), 10 sweep cycles per axis on each of 3 mutually perpendicular axes
• Shock
IEC60068-2-27 (Test Ea), 15 G peak, 11 ms duration, three shocks in each direction
per axis, on 3 mutually perpendicular axes (total of 18 shocks)
• Noise Immunity
NEMA ICS3-304
RFI, (145 MHz, 440 Mhz 10 W @ 10 cm)
Impulse 1000 V @ 1 µs pulse
• Enclosure
NEMA 4/4X, IP-65 (When mounted correctly, for indoor use only.)
• Agency Approvals
CE (EN61131-2), UL508, CUL Canadian C22.2 No. 142-M95, UL File E157382
Physical:
• Dimensions
6.850” (W) x 5.331” (H) x 2.13” (D) [174.0 mm x 135.4 mm x 54.1 mm] (Landscape Mode)
5.331” (W) x 6.850” (H) x 2.13” (D) [135.4 mm x 174.0 mm x 54.1 mm] (Portrait Mode)
• Enclosure Mounting
Thickness Range
0.04” – 0.2” [1 – 5 mm]
• Mounting Clip Screw
Torque Range
21 – 28 oz-in [0.15 – 0.2 Nm]
• Depth from bezel rear
1.894” [47.1 mm]
• Weight
30.69 oz. (870 g)
