CAST XFP 16 ZONE ANALOGUE ADDRESSABLE FIRE ALARM PANEL
ENGINEERING MANUAL • Approved Document No. DFU5010000 Rev 4 • Page 29 of 48
FIX DUPLICATE ADDRESSES
This function helps to locate and fix devices with duplicate (double) addresses and also activates device
(polling) LEDs.
If there is a duplicate address a fault may have been displayed
at the panel, e.g. ‘There are faults on this zone’ (see right).
Enter AL3 (4444) > Commissioning Functions > Address Functions > Fix Duplicate Addresses.
When the FIX DUPLICATE ADDRESSES prompt is displayed, press the Accept
4button.
The panel will re-initialise and check the loop. Wait for the re-initialise process to finish.
Press Menu button and the LED of the first duplicate address will be lit steady red, also details of the
first duplicate address found will appear, for example:
The panel will suggest a new address for the duplicate device. Press the Accept
4button to change
to the new address, or press scroll
5and6 buttons and Accept 4button to select the new address.
The LED of the second duplicate address will now be lit steady red, also details of the second duplicate
address found will appear. The panel will display the following, for example:
The panel will suggest a new address for the original device. Press the Accept
4button to change to
the new address, or press scroll
5and6 buttons and Accept 4button to select a new address.
The panel will confirm there are no duplicate addresses on the loop shown below:
Press Escape
3 button x 3 and the panel will force a loop learn on exiting access level 3. Wait for
the loop learn to finish.
When requested by the panel fit the NVM link shown below:
The typical display shown below will appear:
Press Accept
4button and Escape 3 button. Remove the NVM link when requested by the panel:
Loop: 1 Device: 10
New Address: 8 [ORIGINAL]
Loop: 1 Device: 8
New Address: 3 [DUPLICATE?]
No Duplicate Addresses on the Loop
Please fit the NVM Link now
9 Devices Found
Auto learn complete, Press Accept
Remove NVM Un-Lock Link
Zone 1:
Kitchen
There are faults on this zone
